Home / 20.820
€368,00
Add to cart

20.820

20.820
€368,00
* Excl. tax Excl. Shipping costs
Article number:
20820-835
Weight:
26.7kg
Delivery time:
From stock

UKB-System Amada - Die blocks Read more..

Video
Download DXF
From stock

  • Quality

    use of the optimum materials

  • Consultation

    competent and qualified advice

  • Accessibility

    reliable clearing and delivery

  • Know-how

    more than 30 years of experience

Information

20.820


Tooling system UKB-System Amada
Angle 85°
Die opening V = 32/40 mm
Intake radius R = 4,0 mm
Height 80 mm
Load 1000 kN/m max.
Material C45, 650 - 800 N/mm2


1500 kN/m if the tool clamping has
the corresponding load





Tool lengths



DIES



835 mm
Ondergereedschappen lengte 835 mm



415 mm
Ondergereedschappen lengte 415 mm



800 mm sectionalized

9 Segments

Sectionalized dies are delivered as a complete set
Dies length 800 mm sectionalized
